  #1
January 25th, 2007, 08:32 AM
Rachel's Avatar Just Rachel
Join Date: Oct 2004
Location: Taneytown, MD
Posts: 114,376
Send a message via Yahoo to Rachel
First off you'll need to type out your text as you normally would. I usually use a non-script font and rather large. This is Decker font at 100 pt.



Now, double click on your text layer to bring up your Blending Options Menu.

You want to set your Blend Mode to Multiply as shown here. Your settings should look like this:



Next, click on Bevel and Emboss and set your Technique to Chisel Hard as shown here:



Finally, (and this is the tricky part) click on the Contour box and the Contour Editor will pop up. You'll want to move the editor to look something like this.



It will fight you, but as long as you get it close to this, you'll get the effect. (You can save the contour so that you can use it later to avoid having to do this step each time!)

Then click on OK and you have your text that looks like glass.



Maddie or Misty, could you try it in Elements and see if you get the same effect. If not, I'll try to play around myself in there before my trial expires.
Reply With Quote
  #2
January 25th, 2007, 09:33 AM
Veteran
Join Date: Jan 2007
Posts: 138
YAY YAY It's AWSOME thank you very much.

Now for the next question how do you make it transparent or see-through like I have seen> TIA SO VERY MUCH :!!!
__________________
<div align="center"></div>
<div align="center"></div>
Reply With Quote
  #3
January 25th, 2007, 09:40 AM
Linz's Avatar Slacker Extraordinaire
Join Date: Mar 2006
Location: midwest suburbia
Posts: 63,922
Cool, I'll have to try it later in PSE. It's been a crazy day so far, no time to play.
__________________


**thanks to trish for C's birthday siggy**
Reply With Quote
  #4
January 25th, 2007, 10:35 AM
BrandiiNikkii.*'s Avatar Mommy to Girls ♥
Join Date: Jan 2006
Location: NC
Posts: 13,666
Is there a way to do it in PSP XI?
__________________
Brandi.
Wife to Mark & loving mommy to Caitlin & Lorelai.


Reply With Quote
  #5
January 25th, 2007, 11:16 AM
Corey's Avatar Mega Super Mommy
Join Date: Sep 2005
Location: Indiana
Posts: 2,547
Send a message via Yahoo to Corey
i cant figure it out in Elements 5.0! Dang! i tried to just use the Layer style WOW Plastic and Bevel, but even if i adjust the Opacity, it still does not look the same. its not shiny looking glass. i'm trying but so far no luck....
__________________

Reply With Quote
  #6
January 25th, 2007, 12:00 PM
Rachel's Avatar Just Rachel
Join Date: Oct 2004
Location: Taneytown, MD
Posts: 114,376
Send a message via Yahoo to Rachel
Quote:
i cant figure it out in Elements 5.0! Dang! i tried to just use the Layer style WOW Plastic and Bevel, but even if i adjust the Opacity, it still does not look the same. its not shiny looking glass. i'm trying but so far no luck....[/b]
I'll take a look at it later and see if it can be done in Elements. I'm pretty sure it can be.
Reply With Quote
  #7
January 25th, 2007, 12:20 PM
Rachel's Avatar Just Rachel
Join Date: Oct 2004
Location: Taneytown, MD
Posts: 114,376
Send a message via Yahoo to Rachel
Quote:
Is there a way to do it in PSP XI?[/b]
I don't know how to do this in PSP. I need to sit down with it and try some different things. If I can find a link to another tutorial, I'll post it here.
Reply With Quote
  #8
January 25th, 2007, 01:02 PM
Rachel's Avatar Just Rachel
Join Date: Oct 2004
Location: Taneytown, MD
Posts: 114,376
Send a message via Yahoo to Rachel
Okay I have a style that can be added to Elements and it does the work for you. Anyone who wants it can PM me with an e-mail address and I'll send it off.
Reply With Quote
  #9
January 25th, 2007, 01:57 PM
Linz's Avatar Slacker Extraordinaire
Join Date: Mar 2006
Location: midwest suburbia
Posts: 63,922
Thanks Rachel! I love shortcuts. I'll play more later, but I just made this to see if it would work.

__________________


**thanks to trish for C's birthday siggy**
Reply With Quote
  #10
January 25th, 2007, 02:13 PM
Rachel's Avatar Just Rachel
Join Date: Oct 2004
Location: Taneytown, MD
Posts: 114,376
Send a message via Yahoo to Rachel
Quote:
Thanks Rachel! I love shortcuts. I'll play more later, but I just made this to see if it would work.

[/b]
Lindsay it looks great! I'm glad it worked!
Reply With Quote
  #11
January 25th, 2007, 03:07 PM
Miss.Tee
Guest
Posts: n/a
Quote:
Maddie or Misty, could you try it in Elements and see if you get the same effect. If not, I'll try to play around myself in there before my trial expires.[/b]
I'm getting ready to try. I'm excited


*ETA*

Ok, I cant find the Contour Editor, so I'm kind of stuck. I've searched the help but havent had any luck.
Reply With Quote
  #12
January 25th, 2007, 07:30 PM
Marissa's Avatar Platinum Supermommy
Join Date: Oct 2006
Posts: 8,703
Send a message via MSN to Marissa Send a message via Yahoo to Marissa
I don't know if i got it right.



I had to fight it to get it something like yours.
__________________
Marissa
=)
Reply With Quote
  #13
January 25th, 2007, 07:51 PM
Rachel's Avatar Just Rachel
Join Date: Oct 2004
Location: Taneytown, MD
Posts: 114,376
Send a message via Yahoo to Rachel
Quote:
I don't know if i got it right.



I had to fight it to get it something like yours.[/b]
Nicely done!

Quote:
<div class='quotetop'>QUOTE
Quote:
Maddie or Misty, could you try it in Elements and see if you get the same effect. If not, I'll try to play around myself in there before my trial expires.[/b]
I'm getting ready to try. I'm excited


*ETA*

Ok, I cant find the Contour Editor, so I'm kind of stuck. I've searched the help but havent had any luck.
[/b][/quote]

You want the short cut? Send me your e-mail address.
Reply With Quote
  #14
January 25th, 2007, 08:21 PM
Veteran
Join Date: May 2006
Posts: 262
I made my first siggy using this effect, thanks for the tut!!

Reply With Quote
  #15
January 25th, 2007, 08:58 PM
Rachel's Avatar Just Rachel
Join Date: Oct 2004
Location: Taneytown, MD
Posts: 114,376
Send a message via Yahoo to Rachel
Quote:
I made my first siggy using this effect, thanks for the tut!!

[/b]
Nicely done! You're welcome!
Reply With Quote
  #16
January 25th, 2007, 11:25 PM
Marissa's Avatar Platinum Supermommy
Join Date: Oct 2006
Posts: 8,703
Send a message via MSN to Marissa Send a message via Yahoo to Marissa
I did another one with a bigger font.

__________________
Marissa
=)
Reply With Quote
  #17
January 26th, 2007, 04:41 AM
BrandiiNikkii.*'s Avatar Mommy to Girls ♥
Join Date: Jan 2006
Location: NC
Posts: 13,666
Quote:
Quote:
Is there a way to do it in PSP XI?[/b]
I don't know how to do this in PSP. I need to sit down with it and try some different things. If I can find a link to another tutorial, I'll post it here.
[/b]

Thanks!


I did it in PS But I just plan out SUCK at PS. So I dont really use it that much.
__________________
Brandi.
Wife to Mark & loving mommy to Caitlin & Lorelai.


Reply With Quote
  #18
January 26th, 2007, 09:03 AM
Jacquie's Avatar Platinum Supermommy
Join Date: Jul 2005
Posts: 8,973
Great tutorial Rachel! I just wanted to add 2 things that might help some people that are having trouble.

1. The Contour Editor that you want to open is the Gloss Contour editor on the Bevel and Emboss section, not the Contour checkbox that is a subsection of Bevel and Emboss. (see diagram below) In order to open the Gloss Contour editor, you need to click on the picture in the drop down box, not the arrow - clicking the arrow will drop down a list of pre-defined contour choices.



2. Once you have the Contour Editor open, you can set the anchor points by typing in exact coordinates, rather than guessing where to drag them to. When you first open the editor, you should have 2 anchor points, one at the bottom left, and one at the top right. Click anywhere in the middle of that diagonal line to create another anchor. When the anchor is created, you'll see that you have editable textboxes at the bottom. Here are the coordinates that I used for each of the 3 anchors:

Anchor 1 - Input: 35 Output: 67
Anchor 2 - Input: 65 Output: 41
Anchor 3 - Input: 74 Output: 82

By entering these numbers after creating an anchor, the anchor will move to the desired position!



These are my results using those anchor point coordinates.
